• PTFE隔膜更加耐久

此款 1/4 英寸(6.3mm)气动双隔膜泵配备特氟龙（PTFE）或山道橡胶膜片，性能卓越，可选聚丙烯、导电乙缩醛和聚偏氟乙烯（PVDF）材质8abe8857e02e377ad8c91aa77e52255d。

技术规格

最大工作压力 .................................................................................... 100 psi (0.7Mpa，7bar)

最大流量 ........................................................................................... 19 lpm (1.14m3/h)

最大往复速度 干运转 ..........................................................................320 cpm

湿运转 ....................................................................................................250 cpm

每往复流量 ............................................................................................. 0.020 gallon(0.076 liter)

最大自吸高度 (干抽)D12096 .................................................................. 8-10 ft.(2.5-3 m)

根据阀座，球和隔膜的不同组合而变化

最大输送固体颗粒 ....................................................................................0.06 in.(1.5 mm)

最大空气消耗量 .......................................................................................9.0 scfm (0.252m3/min)

空气进口尺寸 ..........................................................................................1/4 in.npt(f)/1/4 in.bsp(f)

流体进口尺寸 ..........................................................................................1/4 in.npt(f)/1/4 in.bsp(f)

流体出口尺寸 ..........................................................................................1/4 in.npt(f)/1/4 in.bsp(f)

空气出口尺寸 ..........................................................................................1/4 in.npt(f)/1/4 in.bsp(f)

重量：聚丙烯泵：2.0 lbs.(0.9 kg)

乙缩醛泵 ...................................................................................................... 2.5 lbs.(1.1 kg)

PVDF泵 ......................................................................................................... 2.8 lbs.(1.3 kg)

浸液部件 聚丙烯泵 ..............................................Glass-filled Polypropylene,PTFE,Polypropylene

乙缩醛泵 .............................................................. Acetal with SST fibers,Tedlon,Acetal

PVDF泵 ........................................................................................................PVDF,PTFE

在70psi和125cpm情况下的噪音级别 ............................................................... 70dBA
